The XC-523MAX is designed for professional tire service with a center-post wheel locking system, tilting column, automatic tire tip, assist arms and pneumatic controls to support efficient mounting and demounting operations.
The XC-523MAX combines automatic and pneumatic assistance systems to help technicians perform tire removal and installation efficiently while maintaining accurate wheel positioning and controlled operation.
The center-post locking system secures the wheel through the rim center using a locating pin, centering cone and quick-locking handle. This diskless work system keeps the wheel positioned on the machine during mounting and demounting.
The tilting column opens the working area above the wheel, while the automatic tire tip and right-side assist system support the tire bead during removal and installation. Dedicated valves and pedals control the column, tire support, turntable rotation and pneumatic assistance.
The machine is intended for trained professionals. Power supply, compressed air, installation, inflation and maintenance should follow the requirements in the complete user manual.
Wheel centering and locking through the rim center supports secure professional operation.
Rear-swing column operation creates clear working space above the wheel during service.
Assist components help control and press the tire during mounting and demounting operations.
Support mechanisms help position and control the tire bead during professional service work.
Dedicated controls operate turntable rotation, tire support, column tilt and assist functions.
Durable construction and practical controls support regular workshop tire-service operations.
Key technical parameters from the operation manual for quick product evaluation.
The user manual describes the main operating sequence for tire removal and installation.
Position the wheel on the work platform, center it through the rim and secure it using the locking system.
Use the assist arm system, mounting head and rotating work disc to control the bead and remove the tire.
Check tire and rim compatibility, lubricate the bead, mount the tire and inflate according to the stated safety limits.
Download the complete user manual for installation, commissioning, tire removal and fitting procedures, inflation, maintenance, troubleshooting, electrical diagrams and pneumatic diagrams.
